Prepare your product enquiry
Prepare your pin enquiry around the complete part and mating assembly, not just a photograph or nominal diameter. We review standard and drawing-based requirements and confirm the quotation scope before an order.
Dowel pins
Provide the nominal diameter, length, tolerances and end details. Include the mating-hole drawing and required fit; identify removal features if specified. A smooth pin and a spring pin should not be treated as interchangeable.
Clevis pins
Send shank diameter, head dimensions, usable length and cross-hole diameter and position. Identify the mating bracket and the specified retaining component so the complete arrangement can be quoted.
Spring pins
Identify slotted or coiled construction explicitly. Include diameter, length, mating-hole requirements and the specified duty or product reference where applicable. Installation and assembly suitability follow the approved drawing, not a generic diameter substitution.
Split / cotter pins
State the exact pin reference or drawing, nominal size, length convention, material and finish. If supplied with another part, identify the required hole and retaining arrangement.
Enquire about Split / cotter pins →
Quotation information checklist
These fields describe order inputs, not a stock table or engineered acceptance criteria.
| Requirement | Information to provide |
|---|---|
| Product identity | Pin type, exact standard and edition or drawing number and revision |
| Dimensions | Diameter, length, tolerances, chamfers, head and hole details as applicable |
| Mating assembly | Hole sizes, engagement length, fit, retaining part and installation access |
| Material & finish | Material designation, hardness if specified, coating and finished-condition requirements |
| Inspection | Acceptance criteria, documents, lot identification and any sample-review requirement |
| Order | Quantity by size, packing, destination and requested delivery terms |
Common purchasing questions
Is a diameter enough to quote a pin?
No. Include pin type, length, tolerances, mating-hole requirements, material, finish and quantity. Head or cross-hole details may also be required.
Can I replace a dowel pin with a spring pin?
Do not assume interchangeability. The approved assembly requirements and mating holes must be reviewed before changing the pin construction.
Can you review a drawing-based pin enquiry?
Send a controlled drawing and order requirements. Geometry, manufacturing feasibility, inspection scope, minimum quantity and timing are confirmed in the quotation.
MOQ, production timing, material availability, finish and inspection scope are confirmed for the final specification. Product images illustrate appearance only; they do not establish dimensions, approvals or load ratings.
Related products and order guides
- Specification checklist for Pins
- Retaining Rings
- Inspection & Packing Checklist
- Drawing-based custom requirements
Technical context and scope
General references checked 4 October 2026. These sources explain product terminology and specification fields; their product data, certifications and performance values are not FastenerBridge supply claims. Use the exact selected product reference and approved drawing for final requirements.
